The Stuska TrackPack Universal Test Stand (UTS) is an affordable, high-value engine dynamometer system engineered for long-term durability and reliability. The universal test stand provides a rugged, convenient platform at an affordable price, featuring a welded engine frame. Available with either the XS-111 or XS-211 water brake, the UTS can also be supplied with numerous accessories to fit almost any application.
The system is built on the reliable Stuska water brake, seamlessly integrated with the advanced WinDyn™5 control platform. This combination delivers powerful testing capabilities in a streamlined design. Its compact, proven test stand equipped with SuperFlow’s high-performance data acquisition system, provides precise measurement and comprehensive analysis capabilities.
Designed for low-volume performance engine testing, the Stuska TrackPack UTS offers a cost-effective, complete dynamometer package. It provides an affordable solution for testing high-speed diesel, gasoline, alternative-fuel, small engines, and light aircraft engines.
Each UTS can be configured with either the XS-211 water brake rated to 1,000 hp (745 Kw) or the XS-111 rated to 800 hp (596 kW), giving you the flexibility to match your specific testing requirements. The TrackPack UTS is optimized for efficiency, ease of operation, and consistent performance.
| Power and Torque | |
|---|---|
| Absorber Type | Water brake, bi-directional |
| Maximum Speed | 9,000 rpm; 11,000 rpm Intermittent |
| Horsepower Capacity | XS-211: 1,000 hp (745 kW) |
| XS-111: 800 hp (596 kW) | |
| Torque Capacity | XS-211: 1,330 lb-ft (1,803 Nm) |
| XS-111: 656 lb-ft (889 Nm) | |
| Water Requirements | |
|---|---|
| Required | 10 gallons per minute (gpm) for each 100 hp (75.5 kW) |
| Included | Dynamometer supply water pump |
| Stand Sensor Compliment Includes | |
|---|---|
| Temperature | (1) One: (16) Sixteen-channel thermocouple panel |
| (1) One: Closed tip thermocouple, 25 in (.3175 cm) dia. x 4 in (101 mm) long probe with 5 ft. (152 cm) lead, 0° to 2,000°F (-17.8° – 1,093°C) | |
| (1) One: Swagelock fitting | |
| (1) One: 10 ft (3.048 m) extension cable | |
| Pressure | (1) One: (10) Ten-Channel pressure panel |
| (3) Three: Transducers included standard (-15 to 150 psi, 1-10 bar) | |
| Air / Fuel | (2) Two: Pre-configured analog inputs (Lambda/AFR) |
| Optional: Fuel and Air Flow measurement turbines | |
| Additional Thermocouples | Sold Separately |
